STraffic Urban Railway TCS as adopted Korean CBTC, KTCS-M

Korean Train Control System ST-KMX. ST-KMX, STraffic Urban Railway TCS, was a wireless signaling system in the Ilsan Line project. It successfully worked and verified its reliability and performance. Thanks to this reference, we could lay a basis for unmanned infrastructure and a Korean TCS. ST-KMX is a wireless-based urban railway TCS that meets Korean Railway and RAMS standards. The Korean CBTC is a wireless-based TCS that uses WIFI or LTE-R to send real-time information. We would like to provide you with information about our system's configuration. There is a transponder tag installed on the railway track to send information. A signal control device is installed on a vehicle to estimate details such as train location. Three wireless devices receive and process this information. The first device is a ground signal control installed in machine rooms and stations. The second device is an EIS set up in interlocking stations for line conversion, course setting, and course release. The final device is the ATS, which manages all signal information. The last component is a two-way wireless communication device that connects each control system.

Hi-pass system manufacturing and purchase in 2022 (including installation)

The Asan-Cheonan Expressway connecting Asan and Cheonan in South Chungcheong Province opens on the 20th Sep.,2023. It is the first highway connecting Asan, South Chungcheong Province to the Gyeongbu Expressway, the national transportation network. The Ministry of Land, Infrastructure and Transport announced on the 19th that the Asan-Cheonan Expressway connecting Yeomseong-ri, Yeomchi-eup, Asan-si, Chungcheongnam-do, and Cheonan-ri, Mokcheon-eup, Dongnam-gu, Cheonan City, is scheduled to open at 10 p.m. on the 20th. It is a 20.57km four-lane highway that began construction in December 2015 and was built over a period of about 8 years with a total project cost of 1.5 trillion won. With this opening, the travel distance from Yeomchi-eup, Asan-si to Dongnam-gu, Cheonan-si will be reduced by 7.9km, and the driving time is expected to be shortened to 17 minutes (29 minutes → 12 minutes).

Operation & Maintenance of the Padma Bridge and Associated Facilities for 5 Years

STraffic won a project to build a toll collection system on the Padma Bridge and N8 Expressway in Bangladesh, which is a national project in Bangladesh, and Korea Expressway Corporation manages and operates this project. In the past, most of the tolls were paid in cash when passing through toll booths, but after the Toll Collection System Project, tolls are paid with high-pass facilities automatically. STraffic is also carrying out the construction of a traffic monitoring center (TMC) in the sales office, and providing a system that can grasp the traffic volume, traffic situation, and receipt status of the Padma Bridge at a glance through a closed circuit.

Auto Fare Collection: Design, Development and implementation of New Faregate System and Integration with Legacy Fare Payment System

  WMATA(Washington Metropolitan Area Authority) was engineered with attention to aesthetics and design as integral to its form and functionality as a transportation system for Washington, D.C., as the nation's capital.   As the next step in its fare modernization program, WMATA selected STraffic to introduce a new and technologically advanced faregate design and operating system. STraffic designed and manufactured the new faregate to deliver the highest levels of reliability, performance, and security available in the industry. Features include flexible, user-friendly and ADA compliant design that assures that fare gates admit fare-paying riders with safety, convenience, and ease while maintaining order, security, and revenue accountability. To enhance user interfaces for all end-users, particularly WMATA's internal staff, STraffic has provided web-based GUIs for the Faregate Central System (including Station Terminals and Portable Station Manager Devices) that provide easily read, color-coded display for showing the status of each Mezzanine and fare gates. The new faregates and central operating system fully integrate with WMATA's legacy fare payment system to provide seamless, reliable access to Metro subway service.

ITS improves overall traffic in terms of safety, efficiency, and comfort to Medellin city in Colombia

    Medellin ranks as Colombia's most important economic urban area, and is its second most populated city. Mdellin's economic growth spurred demand for vehicles and motorcycles, which has resulted traffic congestion. To cope with traffic congestion, Medellin a multi-year project to implement advanced technology to monitor traffic flow and provide information needed to manage and redistribute traffic flow.     Key Components:

Toll Collection Equipment and Software Solutions for M1&M3 Highways

  STraffic’s responsibilities for this Project include detail design, integration, manufacture, supply and delivery, testing commissioning, warranty, and documenting of RFID technology-based solution to build a complete Toll Collection System for the M1 highway from Yasma to Gusar, a distance of 192km. This system consists of No-Tag, ETCS (Electronic Toll Collection System), Hybrid and MLFF(Multi-Lane Free Flow), and Toll Clearing Center. This solution is “future-proofed” with certified technologies that enable the State Agency of Azerbaijan Automobile Roads to advance to unstaffed operation in the next phase. Once fully implemented, STraffic’s Toll Collection System (TCS) using RFID technology for Yasma-Gusar M1 Road will reduce processing time for collecting tolls, and enable greater administrative efficiency and revenue accountability. Automation has also stabilized operational performance by increasing the availability of equipment, reliability of data, and control over revenues.

Full scale replacement and upgrade of Seoul’s 275 stations transportation card system in South Korea

  In May 2017, Seoul Transportation Corporation initiated integration of Seoul Metro with Seoul Metropolitan Rapid Transit Corp. Together, they operate eight subway lines and serve 2.1 billion riders annually, the highest ridership in the world over a system that is third-largest globally in the length of service routes (300 kilometers), and fourth-largest in the number of urban stations (277 stations).STraffic was chosen to provide and maintain an automated fare system (AFC) that supports all fare transaction processing, including settlement among different entities in Seoul Transportation Corporation’s integrated service network.

Learn more

Installation of advanced Train Telecommunication Systems for Gimpo Urban Railway

STRAFFIC has been awarded the project for the Gimpo Urban Railway, which aims to enhance the transportation infrastructure in Gimpo City. This project involves the implementation of advanced railway signaling and communication systems to ensure efficient and safe train operations. Legacy train control and communication system had performance limitations, making them incompatible to support high-tech, high-speed automated with recently developed with VHF (Voice-only) ultra-short wave and voice communication technology. Another consideration in evaluating the need for alternative equipment was high equipment installation costs (8% of construction costs) and supply and maintenance costs.      Utiling LTE technology-Long Term Evolution, 4th generation high-speed data mobile communication standards, allows railway control systems to manage operations to be more responsive to needs of passengers and advanced railway services by integrating a variety of train control and communication systems installed on each route. This integration supports safer, seamless-operation of all rail transportation options-urban commuter genral inter-city, and high-speed system. Korea's Ministry of Land, Infrastructure, and Transport is leading efforts for the construction of railway communication networks nationwide from 2018 to 2027 to create an integrated system using LTE technology.

Learn more

The Vertical Platform Screen Door enhancing the safety of passengers in Barcelona

  STraffic is also conducting a pilot project with Barcelona's Urban Transportation Bureau (TMB) for a pilot project at "Can Cuias Station" on line 11.

Learn more

Installation of Automated Fare Collection System for an extension of the Jaipur Metro Line

  STraffic will install new AFC equipment at two stations of Jaipur's nine stations of originally equipped with AFC by Samsung SDS in 2013.Both stations, Chhoti Chauper and Badi Chaupar, are underground stations with transfer connections to Chand Pole Station at the center of City Place, a key tourist attraction in Jaipur.

Learn more

The Vertical Platform Screen Door enhancing the safety of passengers in Paris

  Since 1900, Métro de Paris with its extensive network of 16 subway routes has served Parisians and many visitors by providing a quick, efficent way of reaching the destinations that define Paris's culture, economy, and history. Service across the network is provided by a diverse fleet of metro subway cars, with each fleet having a different configuration of doors.  A key concern at Metro de Paris is rider safety while awaiting trains on platforms. Therein lies the challenge: to improve platform safety, traditional platform doors would work only if the car fleet is uniform, and if stopping is precisely aligned with platform door openings.To improve safety and service, Metro de Paris chose STraffic to install Vertical Platform Screen Doors(VSPD) at select stations. Instead of opening horizontally, STraffic developed an innovative solution that opens vertically, like a garage door, to create an open, 8m space for boarding. The solution accommodates differences in subway card door configurations and offers protection for riders, while easily adapting to a variety of station spaces in European railway by virtue of its compact design.
